IP LED18 Pixel Washer

Name: IP LED18 Pixel Washer
Brand: Both Lighting
SKU: SKU:LE318
Availability: InStock
Rating: 5 (1 reviews)

SKU:LE318

IP65 Waterproof 18PCS LED Pixel Wall Washer Bar Outdoor Light RGB/RGBW/RGBWA/RGBWA+UV

Get A Quote Add to Quote List

Main features:

Light source:18PCS LED
9W RGB 8/23/54 CH
10W RGBW 9/23/72CH
12W RGBWA 10/28/90/100CH
15WRGBWA+UV 11/29/108/119CH
Lens degree:40°/25°
Control Signal: DMX 512,Master&slaver ,Auto
Operate Mode: Auto-run mode,Master/Slave mode
Each LED can be Controlled individually
IP rate:IP65

Product Description

Videos

Features

Projects

Product Description

【Efficient RGB Illumination System】
Equipped with 18PCS LEDs, offering four versatile configurations to match varied lighting needs: 9W RGB (8/23/54 CH), 10W RGBW (9/23/72 CH), 12W RGBWA (10/28/90/100 CH), and 15W RGBWA+UV (11/29/108/119 CH). This range covers full-color mixing, warm white supplementation, and UV effects for rich, layered illumination. Offers selectable lens degrees (40°/25°) to tailor beam width for different spaces—from wide-area washes to more focused illumination.

【Versatile Control Modes】
Supports DMX 512, Master&Slave, and Auto control signals, along with Auto-run and Master/Slave operate modes—adapting to professional stage setups, standalone use, or synchronized multi-unit systems. Each LED can be controlled individually, enabling intricate, customized lighting patterns and pixel-level effects.

【Durable & Reliable Design】
IP65-rated for waterproof, dustproof protection, ensuring stable performance in outdoor or harsh indoor environments.

OPTICS

Light source: 18PCS LED
9W RGB 8/23/54 CH
10W RGBW 9/23/72CH
12W RGBWA 10/28/90/100CH
15WRGBWA+UV 11/29/108/119CH
Each LED can be Controlled individually
Lens degree:40°/25°
Dimming: 0-100% smooth dimming

CONTROL

Protocols: Auto mode/ DMX/ Master and Slaver/Voice active
Function Effect:dimmer, strobe, eotic, gradual change
DMX Signal Cable: 3XLR connector
LCD Display,4 buttons operate

POWER CONSUMPTION

Input voltage range:100-240V~50/60Hz
Power consumption: 200W

PHYSICAL

Power connector in/out
IP Rated: IP65
Data in/out: 3-pin XLR
Dimensions: 1000*93*170mm
Weight: 7.2kg
