1.High-Precision RGB Laser Output Features a 3W combined laser system with red (500mW/638nm), green (850mW/520nm), and blue (1650mW/455nm) wavelengths, delivering vibrant colors and sharp projections with a narrow beam divergence (<1.1mrad).
2. Multi-Control Professional Operation Supports versatile control via ILDA for graphics, DMX512 for lighting integration, sound activation, and auto mode, accommodating diverse performance and installation requirements.
3. Advanced Scanning & Modulation Equipped with a 25kpps high-speed scanning system and 100kHz analog modulation, enabling smooth, detailed animations and precise beam movement within a ±30° range.
OPTICS
3W RGB Laser
Working temperature: -10C°-45C°
CONTROL
Control mode: ILDA, DMX512, SOUND (sound control),AUTO (self-propelled)
Modulation mode: analog modulation 100Khz
Scanning system: 25kpps ±30°
POWER CONSUMPTION
Voltage: AC110V-240V 50/60Hz
Laser power/wavelength: R (red): 500mW 638nm
G (green): 850mW 520nm
B (blue): 1650mW 455nm
Full power: Test power after passing through the galvanometer
Divergence angle: ca.4mm/＜1.1mrad
PHYSICAL
Casing material: aluminum
Cooling method: air cooling
Size:219(L)*170(w)*130(H)mm
N.W.: 4.0KG
