Product Description
【High-Power Light Source 】
Boasts a powerful combination of 256pcs 3030 white light LEDs (3W each, divided into 32 segments) and 864pcs 5050 RGB LEDs (0.5W each, divided into 96 segments), delivering bright, layered lighting with precise segment control. Backed by an 800W power rating for impactful output and an average LED lifespan of 30,000 hours for long-term reliability.
【Control Modes】
Supports multiple control modes: DMX512, self-propelled (standalone), master-slave (synchronized multi-unit), and voice control, plus RDM functionality for remote configuration and monitoring. Offers 5 channel options (CH09, CH23, CH135, CH151, CH343) to adapt to simple operations or complex, customized programming.
【Dynamic Lighting Effects】
Features 32-bit 0~100% linear dimming for ultra-smooth brightness transitions, paired with dual core functions (wash + flashing) for versatile visual effects. Adjustable flash frequency (1~30HZ) adds rhythmic, high-energy impact, suitable for concerts, festivals, or architectural accents.
【Widely Use for Many Occasions】
Designed for both large-scale events and permanent installations, outdoor events, architectural lighting, or large-scale stage setups, combining high brightness, segmented control, and weather resistance to meet the demands of professional lighting designers and event organizers.
OPTICS
- LED light source:
- 256 x 3W White LEDs (3030 type), arranged in 32 segments.
- 864 x 0.5W RGB LEDs (5050 type), arranged in 96 segments.
- Function: Wash + Flashing effects.
- Strobe Frequency: Adjustable from 1 to 30 Hz.
- Dimming: 32-bit high-resolution, 0~100% linear dimming.
CONTROL
- Protocol: DMX512 (with RDM function for remote management).
- Control Modes: DMX, Self-Running (Auto), Master-Slave, Voice Control.
- Available Channels: CH09, CH23, CH135, CH151, CH343.
POWER CONSUMPTION
- Rated Power: 800W.
- Input Voltage: AC 100-240V, 50/60Hz (Universal Voltage).
- Average Lifespan: 30,000 hours.
PHYSICAL
- Dimensions: 555 x 160 x 400 mm.
- Weight: 13.95 kg.
- IP Rating: IP65 (Dust-tight and protected against water jets).
- Operating Temperature: -20°C to +45°C.
